$0.2124-38.4838 /Meter
| الدفع نوع: | L/C |
| إنكوترم: | EXW |
| أدني كمية الطلب: | 80000 Meter |
| نقل: | Ocean,Land |
| ميناء: | Qingdao,Tianjin |
الظل:
علامة تجارية: لويو
Origin: الصين
مكان المنشأ: الصين
مواد: PVC
خدمة المعالجة: صب, قطع
Material: Unplasticized Polyvinyl Chloride
معيار: GB/T 4219.1‑2008
Diameter Range: DN20‑DN630 mm
Pressure Rating: PN6‑PN20
Standard Length: 4 m / 6 m, custom length
Color: Dark grey (customizable)
Joint Type: Solvent‑cement joint
Key Feature: Acid & alkali corrosion‑resistant, smooth inner wall
Customizable: Yes
| بيع الوحدات | : | Meter |
| نوع الحزمة | : | التعبئة والتغليف القياسية |
The file is encrypted. Please fill in the following information to continue accessing it
| Norminal diameter (mm) | S10 Series PN 1.0Mpa |
S8 Series PN 1.25Mpa |
S6.3 Series PN 1.6Mpa |
S5 Series PN 2.0Mpa |
| Thickness (mm) | Thickness (mm) | Thickness (mm) | Thickness (mm) | |
| 20 | 2.0 | |||
| 25 | 2.0 | 2.3 | ||
| 32 | 2.0 | 2.4 | 2.9 | |
| 40 | 2.0 | 2.4 | 3.0 | 3.7 |
| 50 | 2.4 | 3.0 | 3.7 | 4.6 |
| 63 | 3.0 | 3.8 | 4.7 | 5.8 |
| 75 | 3.6 | 4.5 | 5.6 | 6.8 |
| 90 | 4.3 | 5.4 | 6.7 | 8.2 |
| 110 | 5.3 | 6.6 | 8.1 | 10.0 |
| 140 | 6.7 | 8.3 | 10.3 | 12.7 |
| 160 | 7.7 | 9.5 | 11.8 | 14.6 |
| 200 | 9.6 | 11.9 | 14.7 | 18.2 |
| 225 | 10.8 | 13.4 | 16.6 | |
| 250 | 11.9 | 14.8 | 18.4 | |
| 280 | 13.4 | 16.6 | 20.6 | |
| 315 | 15.0 | 18.7 | 23.2 |
